APC 5.7K VA Basic Rack PDU - 21 x NEMA 5-20R, 6 x NEMA 6-20R - 5.7kVA, 5.7kW - Zero U Rack-mountable (AP7563)
APC 5.7K VA Basic Rack PDU - 21 x NEMA 5-20R, 6 x NEMA 6-20R - 5.7kVA, 5.7kW - Zero U Rack-mountable (AP7563)
Part Number: AP7563
Condition: New
Availability:
Manufacturer Drop Ship
Real time availability
Best of Cleveland Award in the Computers category
Compsource is honored to be named to the Inc. 500|5000 list
Ranked among the top 500 companies
Microsoft authorized Education reseller
HP Qualified Supplies Partner
BBB Accredited Business Since 2000
Also Available
Product Specifications
APC 5.7K VA Basic Rack PDU - 21 x NEMA 5-20R, 6 x NEMA 6-20R - 5.7kVA, 5.7kW - Zero U Rack-mountable (AP7563)
BASIC PDU 120/208V 7.2KW 0U RackMount PERP - 21X5-20 6XL6-20
Manufacturer Part Number: AP7563
Rack PDU,Basic,ZeroU,5.7kW,120&208V,(21)5-20 & (6)L6-20
MANUFACTURER NAME: Apc Schneider
MANUFACTURER PART NUMBER: AP7563
UPC EAN CODE: 731304207924
LANGUAGE: EN
MARKET:US
| General Information: | |
It is a basic rack PDU with a Zero U vertical mounting design. It supports a maximum input current of 20A and operates at 208V. The PDU features 21 NEMA 5-20R outlets and 6 NEMA L6-20R outlets, providing ample connections for IT equipment. It includes a 3-foot power cord with a NEMA L21-20P plug. The unit is designed for reliable power distribution and includes an installation guide, rack mounting brackets, and a toolless mounting kit. | |
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | AP7563 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Basic Rack |
| Product Name | 5.7K VA Basic Rack PDU |
| Packaged Quantity | 1 Each |
| Product Type | PDU |
| Product UPC | 731304207924 |
| Technical Information: | |
| PDU Type | Basic |
| Plug/Connector Type | NEMA L21-20P |
| Receptacle Type | NEMA 5-20R
NEMA 6-20R |
| Receptacle Detail | 21 x NEMA 5-20R
6 x NEMA 6-20R |
| Power Description: | |
| Input Voltage | 208 V |
| Output Voltage | 120 V AC
208 V AC |
| Physical Characteristics: | |
| Color Family | Black |
| Product Color | Black |
| Mounting Orientation | Vertical |
| Mount Type | Rack-mountable |
| Placement | Side |
| Rack Height | 0U |
| Cord Length | 2.95 ft |
| Height | 70" |
| Width | 2.2" |
| Depth | 1.7" |
| Weight (Approximate) | 12.04 lb |
| Miscellaneous: | |
| What's in the box | |
| Country of Origin | India |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty: | |
| Warranty | 2 Year |
