[TAA, BAA_COTS] APC NetShelter SX, Server Rack Enclosure, 42U, White, 1991H x 600W x 1070D mm - For Storage, Server - 42U Rack Height x 19" Rack Width x 36.02" Rack Depth - White - 2254.73 lb Dynamic/Rolling Weight Capacity - 3006.31 lb Static/Statio (AR3100W)
[TAA, BAA_COTS] APC NetShelter SX, Server Rack Enclosure, 42U, White, 1991H x 600W x 1070D mm - For Storage, Server - 42U Rack Height x 19" Rack Width x 36.02" Rack Depth - White - 2254.73 lb Dynamic/Rolling Weight Capacity - 3006.31 lb Static/Statio (AR3100W)
Part Number: AR3100W
Condition: New
Availability:
Manufacturer Drop Ship
Real time availability
Best of Cleveland Award in the Computers category
Compsource is honored to be named to the Inc. 500|5000 list
Ranked among the top 500 companies
Microsoft authorized Education reseller
HP Qualified Supplies Partner
BBB Accredited Business Since 2000
Product Specifications
[TAA, BAA_COTS] APC NetShelter SX, Server Rack Enclosure, 42U, White, 1991H x 600W x 1070D mm - For Storage, Server - 42U Rack Height x 19" Rack Width x 36.02" Rack Depth - White - 2254.73 lb Dynamic/Rolling Weight Capacity - 3006.31 lb Static/Statio (AR3100W)
NETSHELTER SX 42U 600MM WIDE X 1070MM DEEP ENCLOSURE WITH SIDES WHITE
Manufacturer Part Number: AR3100W
Note:
- The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
- These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
- These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.
Physical
- Net Weight 125.09 KG
- Maximum Height 1991.00 mm
- Maximum Width 600.00 mm
- Maximum Depth 1070.00 mm
- Shipping Weight 144.55 KG
- Shipping Height 2118.00 mm
- Shipping Width 752.00 mm
- Shipping Depth 1219.00 mm
- Weight Capacity (static load) 1363.64 KG
- Weight Capacity (dynamic load) 1022.73 KG
- Minimum Mounting Depth 191.00 mm
- Maximum Mounting Depth 915.00 mm
- Rack Height 42U
- Rack Width 19"
- Color White
- Units per Pallet 1.00
- Vertical Posts 16 gauge
- Front Door 16 gauge
- Rear Door 18 gauge
- Roof 18 gauge
- EIA Mounting Rails 14 gauge
- Side Panels 18 gauge
Conformance
- Regulatory Approvals UL 2416, UL 60950-1
- Standard Warranty 5 year repair or replace
- Standards EIA-310-E
Sustainable Offer Status
- RoHS Compliant
- REACH REACH: Contains No SVHCs
MANUFACTURER NAME: Apc Schneider
MANUFACTURER PART NUMBER: AR3100W
UPC EAN CODE: 731304306597
LANGUAGE: EN
MARKET:US
| General Information: | |
Split rear doors improve access and serviceability to rear of rack mounted equipment. The split rear doors help to maximize floor space. Only 11 inches (279 mm) of clearance is required behind the enclosures to allow for door swing. Enclosures include pre-installed joining hardware to join enclosures in a row and provide additional stability to the enclosure. The pre-installed joining hardware includes holes for joining to an adjacent enclosure at 600mm centers or 24in centers depending upon the floor layout. Enclosures are shipped standard with both leveling feet and castors. Leveling feet can be quickly adjusted through the use of a screwdriver or drill, eliminating the need to reach underneath with a wrench. Enclosures with shock packaging are standard enclosures with provisions in the packaging design and enclosure assembly for shipping the enclosures with equipment mounted inside. | |
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | AR3100W |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | NetShelter SX |
| Product Model | AR3100W |
| Product Name | NetShelter SX 42U 600mm Wide x 1070mm Deep Enclosure with Sides White |
| Product Type | Rack Cabinet |
| Product UPC | 731304306597 |
| Technical Information: | |
| Application/Usage | Storage
Server |
| Mounting Preference | No Preference |
| Physical Characteristics: | |
| Color Family | White |
| Product Color | White |
| Dynamic/Rolling Weight Capacity | 2254.73 lb |
| Static/Stationary Weight Capacity | 3006.31 lb |
| Height | 78.4" |
| Width | 23.6" |
| Depth | 42.1" |
| Rack Height | 42U |
| Rack Width | 19" |
| Rack Depth | 36.02" |
| Weight (Approximate) | 275.78 lb |
| Miscellaneous: | |
| What's in the box |
|
| Country of Origin | China |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty: | |
| Warranty | 5 Year |
