Eaton Tripp Lite Series 1.4kW Single-Phase Local Metered Automatic Transfer Switch PDU, 2 120V 5-15P 15A Inputs, 8 5-15R Outputs, 1U, TAA - 8 x NEMA 5-15R - 1.8kVA - 1U Rack-mountable (PDUMH15AT)
Eaton Tripp Lite Series 1.4kW Single-Phase Local Metered Automatic Transfer Switch PDU, 2 120V 5-15P 15A Inputs, 8 5-15R Outputs, 1U, TAA - 8 x NEMA 5-15R - 1.8kVA - 1U Rack-mountable (PDUMH15AT)
Part Number: PDUMH15AT
Condition: New
Availability: 146
Real time availability
Best of Cleveland Award in the Computers category
Compsource is honored to be named to the Inc. 500|5000 list
Ranked among the top 500 companies
Microsoft authorized Education reseller
HP Qualified Supplies Partner
BBB Accredited Business Since 2000
- Shipping Insurance
- Price Match Guarantee
- Terms of Service Guarantee
- Identity Theft Protection
Also Available
Product Specifications
Eaton Tripp Lite Series 1.4kW Single-Phase Local Metered Automatic Transfer Switch PDU, 2 120V 5-15P 15A Inputs, 8 5-15R Outputs, 1U, TAA - 8 x NEMA 5-15R - 1.8kVA - 1U Rack-mountable (PDUMH15AT)
EATON TRIPP LITE SERIES 1.4KW SINGLE-PHASE LOCAL METERED AUTOMATIC TRANSFER SWIT
Manufacturer Part Number: PDUMH15AT
Tripp Lite's 120V 15A metered PDU system with Automatic Transfer Switching (ATS) is an 8 outlet PDU with a digital display to indicate total PDU power consumption in amps. Outlets are sequentially turned on at 250 milliscond intervals when the PDU is first energized from an unpowered state to prevent inrush-related equipment interaction on startup. Supports 1U rackmount installation in a 2 or 4 post rack. Included are 8 NEMA 5-15R outlets, and two 12 ft. 5-15P input power cord
MANUFACTURER NAME: Eaton
MANUFACTURER PART NUMBER: PDUMH15AT
UPC EAN CODE: 003733212665
LANGUAGE: EN
MARKET:US
| General Information: | |
Tripp Lite's 120V 15A metered PDU system with Automatic Transfer Switching (ATS) is an 8 outlet PDU with a digital display to indicate total PDU power consumption in amps. Outlets are sequentially turned on at 250 milliscond intervals when the PDU is first energized from an unpowered state to prevent inrush-related equipment interaction on startup. Supports 1U rackmount installation in a 2 or 4 post rack. Included are 8 NEMA 5-15R outlets, and two 12 ft. 5-15P input power cord. Optional integrated ATS is available for use when two separately derived input power sources are available. The attached power cord serves as the primary AC input cable, while the included detachable power cord serves as the optional-use secondary AC input connection. The PDU system passes the primary input power through to connected equipment whenever line voltage and frequency levels are normal. If the primary input source goes outside of these tolerances or fails altogether, the ATS will automatically switch all PDU output to the secondary line sourced input power (when available) to maintain continuous operation of connected loads without reboots or service interruptions. Once the primary power source is restored, the PDU will automatically switch back to primary sourced input power. The dual input cabling can be configured for UPS maintenance bypass of standard UPS s | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | PDUMH15AT |
| Manufacturer Website Address | http://www.eaton.com |
| Brand Name | Tripp Lite series |
| Product Model | PDUMH15AT |
| Product Name | PDUMH15AT PDU Metered ATS 120V 15A 8 Outlet |
| Product Type | PDU |
| Product UPC | 003733212665 |
| Technical Information: | |
| Plug/Connector Type | NEMA 5-15P |
| Plug/Connector Detail | 2 x NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Power Description: | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Power Rating (VA) | 1800 VA |
| Management: | |
| Management |
|
| Physical Characteristics: | |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.8" |
| Width | 17.5" |
| Depth | 14.5" |
| Weight (Approximate) | 11 lb |
| Miscellaneous: | |
| What's in the box |
|
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Warranty: | |
| Warranty | 2 Year |
Questions and Answers
Questions and Answers | Ask CompSource |
Shipping / Returns
Shipping
Ground =
$29.50
(EST. Arrival Date between
Thu.Apr.23 - Tue.Apr.28)
Two Day Air = $44.00
(EST. Arrival Date on Thu.Apr.23)
Standard One Day = $74.00
(EST. Arrival Date on Wed.Apr.22 after 3PM)
Priority = $110.00
(EST. arrival Date on Wed.Apr.22 in the AM)
U.S Mail Priority (AA,AE,AP only) = $51.33
FedEx International Economy (Canada only) = $104.00
Shipping dates are best estimates based on product location and may vary with holidays.
If product requires trucking, additional fees may apply.
* Some destinations are subject to Applicable State/Duty Taxes
Returns
CompSource realizes that every product may have different return guidelines. Please see the policy below regarding this item.
This Product Has Limited Exchange Privileges.
Limited returns within 30 days of purchase permitted on this product.
For support on this product, please contact Eaton. 800-356-5794 www.eaton.com
Eaton Company's Information
Click Eaton for all products
Toll Free #: 800-356-5794
Tech Support #: 800-843-9433
Site: www.eaton.com
Accessories
Product Reviews
Overall Rating | Write a Review
|
|
Best Sellers
More Best Sellers
About Eaton
The world's demand for power keeps growing
Today, the world runs on critical infrastructure and technology. Planes. Hospitals. Factories. Data centers. Vehicles. The electrical grid. These are things people depend on every day. And the companies behind them depend on us to help solve some of the toughest power management challenges on the planet. At Eaton, we're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable.
We are power management company made up of over 96,000 employees, doing business in more than 175 countries. Our energy-efficient products and services help our customers effectively manage electrical, hydraulic and mechanical power more reliably, efficiently, safely and sustainably. By giving people tools to use power more efficiently. Helping companies do business more sustainably. And by encouraging each and every employee at Eaton to think differently about our business, our communities' and the positive impact we can have on the world.
At Eaton, we're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable. Because that's what really matters. And we're here to make sure it works.
CompSource is a fully-authorized resource for Eaton uninterruptible power supply systems, backup power systems, and power management systems, offering unsurpassed expertise providing emergency UPS systems and high-quality power backup systems for large data centers, electrical engineering infrastructure, and other mission-critical IT applications.
We want this to be as easy and stress-free as possible.
Here are just a few of Eaton's most popular categories;
UPS systems are critical in ensuring that power supply is uninterrupted during power outages, surges, or fluctuations. Eaton's range of UPS systems provides a range of solutions for small to large businesses, data centers, and critical infrastructure. The Eaton 5P series, for instance, is designed for use in small and medium-sized businesses, while the Eaton 9PX series is ideal for use in data centers and critical infrastructure applications.
Eaton also provides a range of power distribution units (PDUs) that help distribute power to multiple devices in data centers and server rooms. Eaton's ePDU G3 series, for example, is designed for high-density computing environments and provides real-time monitoring of power consumption.
CompSource.com is a reputable online retailer that provides a range of IT solutions, including Eaton Corporation's UPS and PDU solutions. Here are some links to their products:
In conclusion, Eaton Corporation's UPS and PDU solutions are designed to provide reliable, efficient, and safe power management solutions for businesses of all sizes. With CompSource.com, customers can easily access and purchase these solutions online, ensuring that their critical infrastructure is always protected.
CompSource is here to help you decide. We have conveniently created this Click this link, this will assist in your UPS selection. You can also Chat with us or give our professionals a quick phone call (800)-413-7361, we can assist with the best Eaton solution for your needs and budget.
Learn more about PDUs
What are Smart or Intelligent PDU's;
In the world of PDUS, there are essentially two types: Basic PDUS and Smart /Intelligent PDUS. The
The Smart/Intelligent label can sometimes generate confusion because it's not a term that corresponds to a singular qualifying product feature. There are a collection of advanced features that when available in a PDU model, make that model smart.
It's important to understand that it's not about having a smart PDU with all the advanced features currently available. It's about establishing what your power management needs are. And going from there. The industry has essentially scripted what are the most common power optimization scenarios, and thus have created a set of Smart PDU sub categories that each address an appropriate scenario.
Smart PDUS are broken down into 4 distinct sub categories:
- Metered Inlet PDUS
- Metered Outlet PDUS
- Switched PDUS
- Switched PDUS with Outlet Metering
