EDGE E3 1 TB 2.5" Internal Solid State Drive - SATA - 560 MB/s Maximum Read Transfer Rate - 460 MB/s Maximum Write Transfer Rate (PE246631)
EDGE E3 1 TB 2.5" Internal Solid State Drive - SATA - 560 MB/s Maximum Read Transfer Rate - 460 MB/s Maximum Write Transfer Rate (PE246631)
Part Number: PE246631
Condition: New
Availability:
Out of stock
Real time availability
Notify Me
Best of Cleveland Award in the Computers category
Compsource is honored to be named to the Inc. 500|5000 list
Ranked among the top 500 companies
Microsoft authorized Education reseller
HP Qualified Supplies Partner
BBB Accredited Business Since 2000
Product Specifications
EDGE E3 1 TB 2.5" Internal Solid State Drive - SATA - 560 MB/s Maximum Read Transfer Rate - 460 MB/s Maximum Write Transfer Rate (PE246631)
1TB E3 SATA SSD 6GB/S 2.5IN Internal -
Manufacturer Part Number: PE246631
Note:
- The full product specifications below are from the manufacturer and may contain information related to other package quantities that will not apply to the product that you are reviewing. Please confirm the actual content and/or package quantity from the main product specifications page.
- These specifications may represent the entire product series/model/line to which this product belongs with specific configuration differences between the individual products stated.
- These specifications may have been copied from the same product in other region/country in which case there might be minor differences in region-specific data such as Input Voltage, Terms of Warranty etc.
Capacity* : 250GB** / 256GB / 500GB** / 512GB / 960GB** / 1TB
Form Factor : 2.5", 7mm height
Interface : SATA 6Gb/s (also compatible with SATA 1.5Gb/s and SATA 3Gb/s)
Dimensions : 100mm (L) x 69.85mm (W) x 7mm (H)
Weight : 0.12 lbs
Certifications : TAA, RoHS, FCC, CE, and WWN compliant
250GB-256GB Max Speed (6Gb/s) : Up to 560MB/s (read) / 315MB/s (write)
500GB-512GB Max Speed (6Gb/s) : Up to 560MB/s (read) / 460MB/s (write)
960GB-1TB Max Speed (6Gb/s) : Up to 560MB/s (read) / 460MB/s (write)
250GB-256GB Max IOPS : 72,000 (read) / 73,000 (write)
500GB-512GB Max IOPS : 74,000 (read) / 76,000 (write)
960GB-1TB Max Speed IOPS : 76,000 (read) / 76,000 (write)
Flash Type : MLC (Sync)
Write Endurance : 3,000 P/E Cycles
Controller : Silicon Motion SM2246EN
Compatibility : Windows Vista and higher, Mac OS X 10.4 and higher, Linux
MTBF : 1,500,000 hours
Security : Supports Software Encryption, User Selectable Password (if BIOS supported), and Secure Erase
External DRAM : 256MB (250GB-256GB models) / 512MB (500-512GB models) / 1GB (960GB-1TB models)
TRIM Support : Prolongs SSD performance over time***
S.M.A.R.T. Support : Monitors and displays reports on SSD health and errors
Wear Leveling Support : Improves the lifespan of the SSD by ensuring that data is written evenly across data blocks
ECC : Avoids errors and promotes stability during data reads/writes
Early Bad Block Retirement : Retires weak data blocks before failing, enhancing drive stability
DataRefresh : Data errors are detected and corrected before becoming problematic
Temperature Sensor : Monitors internal drive temperature
Power Consumption (Typical) : 2W (Active), 0.7W (Idle)
Operating Temperature : 0°C - 70°C
Storage Temperature : -40°C - 85°C
Shock Resistance : 1500G/0.5ms
Vibration Resistance : 2–500Hz at 3.1G
MANUFACTURER NAME: Edge Memory
MANUFACTURER PART NUMBER: PE246631
UPC EAN CODE: 652977246655
LANGUAGE: EN
MARKET:US
| General Information: | |
Balancing performance and reliability, the EDGE™ E3 SSD is a storage upgrade at an exceptional value. Featuring the Silicon Motion SM2246EN controller, E3 SSDs are loaded with enhancements to promote a dependable computing environment. TRIM, Wear Leveling, and ECC functions are included and optimize data processing efficiency. S.M.A.R.T. reporting and a built-in temperature sensor assist with monitoring drive health. Advanced features such as Early Bad Block Retirement and DataRefresh add an additional layer of protection to keep the E3 running at optimum performance. | |
| Manufacturer | Edge Memory |
| Manufacturer Part Number | PE246631 |
| Manufacturer Website Address | http://www.edgememory.com |
| Brand Name | EDGE |
| Product Series | E3 |
| Product Name | 1TB 2.5" E3 SSD - SATA 6Gb/s |
| Product Type | Solid State Drive |
| Product UPC | 652977246655 |
| Technical Information: | |
| Storage Capacity | 1 TB |
| Drive Performance: | |
| Maximum Read Transfer Rate | 560 MB/s |
| Maximum Write Transfer Rate | 460 MB/s |
| Interfaces/Ports: | |
| Drive Interface | SATA |
| Drive Interface Standard | SATA/600 |
| Physical Characteristics: | |
| Drive Type | Internal |
| Form Factor | 2.5" |
| Height | 0.3" |
| Width | 2.8" |
| Depth | 3.9" |
| Weight (Approximate) | 1.92 oz |
| Miscellaneous: | |
| Device Supported | Server |
| Environmentally Friendly | Yes |
| Warranty: | |
| Warranty | 5 Year |
