Eaton Tripp Lite Series SmartPro 1950VA 1950W 120V Line-Interactive Sine Wave UPS - 7 Outlets, Extended Run, Network Card Option, LCD, USB, DB9, 2U Rack/Tower - 1950VA/1950W - 4 Minute Full Load - 4 x NEMA 5-15R, 4 x NEMA 5-15/20R (SMART2200RM2U)
Eaton Tripp Lite Series SmartPro 1950VA 1950W 120V Line-Interactive Sine Wave UPS - 7 Outlets, Extended Run, Network Card Option, LCD, USB, DB9, 2U Rack/Tower - 1950VA/1950W - 4 Minute Full Load - 4 x NEMA 5-15R, 4 x NEMA 5-15/20R (SMART2200RM2U)
Part Number: SMART2200RM2U
Condition: New
Availability: 5
Best of Cleveland Award in the Computers category
Compsource is honored to be named to the Inc. 500|5000 list
Ranked among the top 500 companies
Microsoft authorized Education reseller
HP Qualified Supplies Partner
BBB Accredited Business Since 2000
- Shipping Insurance
- Price Match Guarantee
- Terms of Service Guarantee
- Identity Theft Protection
Product Specifications
Eaton Tripp Lite Series SmartPro 1950VA 1950W 120V Line-Interactive Sine Wave UPS - 7 Outlets, Extended Run, Network Card Option, LCD, USB, DB9, 2U Rack/Tower - 1950VA/1950W - 4 Minute Full Load - 4 x NEMA 5-15R, 4 x NEMA 5-15/20R (SMART2200RM2U)
UPS SMART 2200VA 1920WAVR 120V PERP - 8OUT 2URM LCD USB DB9 RS232 EPO
Manufacturer Part Number: SMART2200RM2U
Eaton Brochure PDF 2200VA / 2.2kVA / 1920 watt line interactive UPS system with high power factor for server, network and telecommunications equipment. 2U rackmount or tower form factor with an installed depth of only 19 inches. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers two levels of voltage boost during brownouts and one level of voltage cut during overvoltages to maintain regulated 100, 110, 120v selectable output over an input range of 83-145V. Includes NEMA 5-20P input plug and both NEMA 5-15R and 5-15/20R output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated 3-bank PDU switching supports load shedding and remote-reboot of connected equipment. 3-stage metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount accessories included; 2-9USTAND tower kit and 2POSTRMKITWM two post rack & wallmount accessories available. Field-replaceable, hot-swappable internal batteries. Attractive all-black color scheme. 2-year warranty and $250,000 connected equipment insurance; extended warranty and service contracts available. SmartPro 2200VA / 2.2kVA / 1920 watt line interactive UPS system with high power factor is ideal for voice, data, medical and industrial networking applications Line interactive Automatic Voltage Regulation (AVR) offers two levels of voltage boost during brownouts and one level of voltage cut during overvoltages Maintains continuous operation through blackouts, voltage fluctuations and surges Corrects line voltage conditions as low as 83V and as high as 145 back to selectable 100/110/120V nominal values Offers 13 minutes at half load (960w) and SmartPro 2200VA (2.2kVA)/1920 watt line interactive UPS system with high power factor for server, network and telecommunications equipment. 2U rackmount or tower form factor with an installed depth of only 19 inches. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers two levels of voltage boost during brownouts and one level of voltage cut during overvoltages to maintain regulated 100, 110, 120v selectable output over an input range of 83-145V. Includes NEMA 5-20P input plug and both NEMA 5-15R and 5-15/20R output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling; Emergency Power Off (EPO) interface; Integrated 3-bank PDU switching supports load shedding and remote-reboot of connected equipment. 3-stage metered current monitoring and battery charge status LEDs; Utility power and voltage regulation LEDs; Audible alarm; Self-test. 4-post rackmount accessories included; 2-9USTAND tower kit and 2POSTRMKITWM two post rack & wallmount accessories available. Field-replaceable, hot-swappable internal batteries. Attractive all-black color scheme. 2-year warranty and $250,000 connected equipment insurance; extended warranty and service contracts available. PowerAlert software CD-ROM USB, serial and EPO cabling Owner's manual with warranty information.
MANUFACTURER NAME: Eaton
MANUFACTURER PART NUMBER: SMART2200RM2U
UPC EAN CODE: 037332150622
LANGUAGE: EN
MARKET:US
| General Information: | |
1.95kVA/1.95kW/120V Battery Backup for Distributed IT, Telecom or Enterprise Deployments Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages Optional LX Platform Network Management Card Allows Remote Access 24/7 NEMA Outlets Protect Your Connected Components Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SMART2200RM2U |
| Manufacturer Website Address | http://www.eaton.com |
| Brand Name | Tripp Lite series |
| Product Line | SmartPro |
| Product Model | SMART2200RM2U |
| Product Name | SmartPro SMART2200RM2U 1950VA Rack/Tower UPS |
| Packaged Quantity | 1 Each |
| Product Type | Line-interactive UPS |
| Product UPC | 037332150622 |
| Technical Information: | |
| AVR | Yes |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA 5-20R
NEMA L5-20R |
| Receptacle Detail | 6 x NEMA 5-20R
1 x NEMA L5-20R |
| Overload Protection | Yes |
| Cord Length | 10 ft |
| Transfer Time | 4 ms |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Energy Saving | Greater than 95% efficiency - GREEN UPS; Individually controllable load banks |
| Application/Usage | Data Storage
Server Switch IT Equipment |
| Power Description: | |
| Load Capacity (VA) | 1950 VA |
| Load Capacity (Watt) | 1950 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 70 V AC - 153 V AC |
| Input Current | 16.40 A |
| Output Voltage | 100 V AC
110 V AC 120 V AC 125 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Pure Sine Wave |
| Surge Energy Rating | 380 J |
| Output Power Factor | 1 |
| Display & Graphics: | |
| Display | LCD |
| Management: | |
| Network Management | SNMP/Web |
| Alarm | Remote Shutdown
UPS StartUp Power Failure Overload UPS Fault Low Battery |
| Controls/Indicators: | |
| Status Indicators | 5 Front Panel Leds:
|
| Interfaces/Ports: | |
| Serial Port | Yes |
| USB | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information: | |
| DC System Voltage | 72 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 4 Minute |
| Backup/Run Time (Half Load) | 12 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 4.50 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions: | |
| Maximum Operating Elevation | 10000 ft |
| Maximum Storage Elevation | 32808 ft |
| Storage Temperature | 5°F (-15°C) - 122°F (50°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 45 dB(A) |
| Physical Characteristics: | |
| Height | 3.4" |
| Width | 17.2" |
| Depth | 23.7" |
| Rack Height | 2U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 65.30 lb |
| Miscellaneous: | |
| What's in the box | |
| Software Included | PowerAlert Software |
| Energy Star | Yes |
| Country of Origin | Philippines |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty: | |
| Warranty | 3 Year |
| Additional Warranty Information | 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty. |
